Cbr Laboratory Elektrik

JS-360 A
ELECTRIC LABORATORY CBR TEST SET
ASTM D-1883 / AASHTO T-193
For determining the bearing ratio of soil.

SPESIFIKASI TEKNIS :

JS-361 A Mechanical Loading Machine “Electric, 220 V-AC, 1/2 HP , 1 Phase, speed 0.05″”/min reversing switch, 10.000 lbs capacity” 1 set

JS-362 CBR Mold Machined steel, 6″ i.d, 7″ weight, 2″ height of collar 3 pcs

JS-363 Spacer Dish Machined steel, 5 15/16″ dia., 2.416″ height 1 pc

JS-364 Cutting Edge Machined steel, sharp edge 1 pc

JS-365 Circular Surcharge Weight “Machined steel, 5 7/8″” o.d., 2 1/8″” i.d, 5 lbsweight ”

JS-366 Slotted Surcharge Weight “Machined steel, 5 7/8″” o.d., 2 1/8″” slotted width,5 lbs weight” 3 pcs

JS-367 Swell Plate Cast Alumunium 149 mm Dia 3 pcs

JS-368 Swell Tripod & Dial 30 mm Cast Alumunium Tripod support dial gauge 1 pc

JS-354 Modified Proctor Hammer “Machined steel, galvanized, 2″” dia., 18″” dropheight, 10 lbs weight ”

JS-369 Filter Paper 6″ dia., 100 sheets/box. 1 box

JG-101/6 Proving Ring 6.000 lbs capacity. 1 set

JG-131 Dial Indicator Range 0.01″ x 1″. 1 pc

JG-303 Square Pan Galvanized steel, 65 x 65 x 7.5 cm. 1 pc

JG-390 Thin Box Alumunium, 60 gr capacity. 12 pcs

JG-405 A Graduated Cylinder Plastic, 1000 ml capacity. 1 pc

JG-801 Scoop Cast alumunium. 1 pc

JG-871 T rowel Pointed type. 1 pc

JG-890 Straight Edge 300 mm length. 1 pc

Dimension (l x w x h) : 110 x 70 x 70 cm Gross Weight : 200 kg
